Thiết Bị Đo Cáp Quang - MSS PON Power Meter
The PPM-350B PON Power Meter is intended for FTTH and FTTP systems. This rugged, lightweight unit comes in one-port and two-port versions. The PPM-350B provides filtered measurements and distinct power values for downstream signals (1490 nm and 1550 nm). The PPM-350B performs quick, accurate measurements, no matter where in the network you need to test, it also offers a threshold based pass/warning/fail analysis.
Download Tài Liệu: Download
- Truly optimized for EPON architectures
- Pass/warning/fail indicators (10 threshold sets) for easy assessment of power values anywhere on the network
- Simultaneous measurements and display of all PON signals: Voice, Data and Video
- Filtered measurements, providing distinct power values for each signal (1310, 1490 and 1550nm)
- Full OLT to ONT communication while testing
- Extended range for testing at the central office (CO) and before the splitter
